Block Diagram Definition. A block definition diagramis a static structural diagram that shows system components, their contents (properties, behaviors, constraints), interfaces, and relationships. Blocks represent the system hierarchy in terms of systems and subsystems.
Function block diagram (fbd) is a graphical language that allows the user to build complex procedures by taking existing function blocks from the iec 1131 compliance library, and wiring them together on screen. There are two kinds of sysml diagrams used to specify the structure of the proposed system (i.e., block definition diagrams and internal block definition diagrams). The block definition diagram in sysml defines features of a block and relationships between blocks such as associations, generalizations, and dependencies.
